Installation of the Y-Strainer

Generally speaking, there are three ways to install the Y-Strainer:

1. Steam or gas pipeline: the Strainer screen faces the horizontal direction;

2. Liquid pipeline: the Strainer screen is installed downwards;

3. Vertical installation: according to the installation direction of the strainer.

Y-Strainer are usually installed at the inlet of pressure reducing valves, pressure relief valves, fixed water level valves or other equipment to remove impurities in the medium to protect the normal use of valves and equipment. The Y-Strainer has the characteristics of advanced structure, low resistance and convenient sewage discharge.

The applicable medium of Y-Strainer can be water, oil and gas. Generally, the water network is 18-30 mesh, the ventilation network is 10-100 mesh, and the oil network is 100-480 mesh. The basket strainer is mainly composed of a connection pipe, a main pipe, a strainer basket, a flange, a flange cover and a fastener. When the liquid enters the strainer basket through the main pipe, the solid impurity particles are blocked in the strainer basket, and the clean fluid passes through the filter basket and is discharged from the filter outlet.
